REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV

REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV

Large Image :  REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV

Product Details:
Place of Origin: Guangdong, China
Brand Name: REISSDISPLAY
Model Number: LO0016670
Contact Now
Detailed Product Description
Application: Indoor, Indoor Warranty: 1 Year
Color: Full Color Supplier Type: Original Manufacturer, ODM, OEM
Use: Indoor Led Display, Indoor Led Screen, Indoor Led Wall Function: SDK
Pixels: 2MM Specification: Video Wall
Screen Type: No Brightness: 1000nits
Aspect Ratio: 16:9 Pixel Density: 250000dots
Contrast Ratio: 30000:1 Color Depth: 14-18bit
Lifespan (hours): 10000hr Ip Rating: IP45
Resolution: 2k/4k/8k View Angle（h/v）: 160:160°
Usage: Indoor Tube Chip Color: FULL COLOR
Display Function: Video Screen Dimension: 320x160mm
Product Name: Led Video Display Panel Brightness: 1000cd/sqm
Refresh Rate: 1920/3840Hz/7680Hz Warranty: 5 Years
Pixel Pitch: 2

REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 0
Product Description
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 2
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 4

REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 6

REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 8

If you need other LED displays (HD indoor screens, stage rental screens, transparent screens, Soft Flexible Curved LED Display...) click here →



Specifications：

Small LED Display (Part of it, contact in detail)

Indoor led module display panel P1.25/P1.5/P1.6/P1.8/P2/P2.5/P4/P5 led video wall screen

With high refresh rate, high brightness, and fast assembling.
With waterproof, light & thin, and good heat dissipation.
Warranty for 5 years . no dead lamp and long time working hours .
Model
P1.2
P1.5
P1.6
P1.8
P2
P2.5
P3
P4
Pixel Pitch(mm)
1.25
1.53
1.66
1.86
2
2.5
3
4
Pixel Matrix Per Sq.m
422500
422500
360000
288906
250000
160000
90000
62500
Pixel Configuration
SMD1212
SMD1212
SMD1212
SMD1515
SMD1515
SMD1515
SMD2121
SMD2121
Cabinet Resolution
415x312
415x312
384x288
344x258
320x240
256x192
192x144
160x120
Power Con.(W/㎡) (Max / Avg)
600W/200W
600W/200W
600W/200W
580W/180W
580W/180W
550W/160W
450W/160W
450W/160W
Refresh Rate (HZ)
≥3840
≥3840
3840
3840
3840
≥1920
≥1920
≥1920
Brightness (cd/㎡)
500-900
Module Dimension
320x160mm / 1.05x0.53ft
Cabinet Dimension
640x480mm / 2.10x1.57ft
Cabinet Material
Die Casting Aluminum
Cabinet Weight
4.6KG
Service Access
Front
Grey Scale (bit)
14-22bit
Viewing Angle (H/V)
160°/160°
IP Rate
IP45
Operation Temperature
-20℃ ~ +80°℃
Input Voltage (AC)
110V / 220V
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 10
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 12
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 14
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 16
Direct connection power cables
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 18
Power supply
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 20
Fast lock
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 22
Receiving card
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 24
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 26
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 28
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 30
Click here for more details
Project Cases
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 32
Part of it：Indoor stage studio
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 34
Indoor stage performance
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 36
meeting room
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 38
Outdoor stage background
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 40
Related Product
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 42
Small Pixel LED Screen
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 44
Rental Type LED Screen
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 46
Fixed Type LED Screen
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 48
Soft Flexible Curved LED Display
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 50
Dance Floor LED Display
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 52
Transparent Mesh LED Screen

Company Profile
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 54
Shenzhen Reiss Optoelectronics Technology Co., Ltd.
Our products have also passed CE, FCC, RoHS certification. Our market depends on competitive prices and high-quality products, and our products have won the trust of many overseas countries. So far, we have established good cooperation with customers from the United States, Germany, Brazil, Italy, Spain, the United Kingdom, Russia, Australia, New Zealand, Japan and other countries. Our market continues to develop towards a broader prospect.
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 56
Certificate
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 58
Our Service
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 60
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 62
Packing & Delivery
REISS Ultra Thin Small Pixel Pitch 16:9 Low Cost Front Service LED Video Wall for 2K/4K/8K LED TV 64
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: It Depend on the sample type, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below.

Q:I would like to ask you if it's possible to have my logo on the product.
A:Yes, Our one-stop service can be customized according to customer requirements ODM/OEM development design production and processing
