Product Details:
|
Application: | Indoor | Warranty: | 1 Year |
---|---|---|---|
Color: | Full Color | Supplier Type: | Original Manufacturer, ODM, Other, OEM |
Media Available: | Datasheet, Photo | Use: | Advertising Publish, Retail Store, Shopping Mall, Welcome Display, Exhibition Hall, Airport, Subway, Elevator, Education, Medical Treatment, Indoor Led Display |
Function: | SDK | Pixels: | 1.86mm |
Specification: | Video Wall | Screen Type: | No |
Brightness: | 600-1000cd/m2 | Aspect Ratio: | 16:9 |
Pixel Density: | 289051dots/m2 | Contrast Ratio: | 30000:1 |
Color Depth: | 14bit-18bit | Lifespan (hours): | 100000hr |
Ip Rating: | IP45 | Resolution: | 4K/8K/16K |
View Angle(h/v): | 178/178° | Operating Environment: | Indoor Led Display |
Pixel Configuration: | 3in1 (1R1PG1B) | Module Size: | 320x160mm |
IP Grade: | IP45 | Life Span: | 100000hr |
Viewing Angle: | 178 /178° | Cabinet Material: | Die Cast Aluminum |
Cabinet Weigh: | 4.6Kg |
Model | Panel-1.25 | Panel-1.37 | Panel-1.53 | Panel-1.66 | Panel-1.86 | Panel-2 | Panel-2.5 | Panel-4 | Panel-5 | ||||||||
Pixel Pitch (Resolution) (mm) | 1.25 | 1.379 | 1.538 | 1.667 | 1.86 | 2 | 2.5 | 4 | 5 | ||||||||
Pixels Per Sq. Meter (Density) | 640,000 | 525,862 | 422,754 | 359,857 | 289,051 | 250,000 | 160,000 | 62,500 | 40,000 | ||||||||
Module Matrix | 256X128 | 232X116 | 208X104 | 192X96 | 172X86 | 160X80 | 128X64 | 80X40 | 64X32 | ||||||||
Scanning Mode | 1/64 | 1/58 | 1/52 | 1/48 | 1/43 | 1/40 | 1/32 , 1/64 | 1/20 | 1/16 | ||||||||
Module Dimensions | 320mmx160mm | ||||||||||||||||
LED Package Type | SMD / GOB (Opitonal) | ||||||||||||||||
Refresh Rate | 1920 / 3,840 / 7680 Hz | ||||||||||||||||
Driving Method | Constant current | ||||||||||||||||
Video Frame Rate | 60 frames/second | ||||||||||||||||
Color Depth | 14 / 16 bit | ||||||||||||||||
Contrast Ratio | 3,000 : 1 | ||||||||||||||||
Brightness | 600 ~ 1,000 NITS | ||||||||||||||||
Brightness Control | 256 levels | ||||||||||||||||
Ideal Viewing Angle | 120°(H) / 120°(V) | ||||||||||||||||
Max. Power Consumption (Approx.) | 600W/m² | ||||||||||||||||
Avg. Power Consumption (Approx.) | 200W/m² | ||||||||||||||||
Input Voltage | AC220V / AC110V | ||||||||||||||||
Operating Temperature | -20 ℃ – +50 ℃ | ||||||||||||||||
MTBF | >5,000 hours | ||||||||||||||||
LED Life – Span | 100,000 hours | ||||||||||||||||
Cabinet Material | Die-casting Aluminum | ||||||||||||||||
Cabinet Size | 640x640mm, 640x480mm, 480x480mm, 320x160mm |
