Product Details:
|
Application: | Indoor | Color: | RGB |
---|---|---|---|
Supplier Type: | Original Manufacturer, ODM, OEM | Media Available: | Datasheet, Photo |
Use: | INDOOR, Indoor LED Video Wall, Indoor LED Screen | Function: | SDK |
Pixels: | 1.25mm | Specification: | Video Wall |
Screen Type: | No | Brightness: | 600-1500nit |
Pixel Density: | 640000dots | Contrast Ratio: | 30000:1 |
Color Depth: | HD - 18 Bit | Lifespan (hours): | 100000 |
Ip Rating: | IP65 Front | Resolution: | 2K/4K/8K |
View Angle(h/v): | 170:170° | Usage: | INDOOR |
Tube Chip Color: | FULL COLOR | Product Name: | Led Video Display Screen |
Module Size: | 320x160mm | Brightness: | 600cd/sqm |
Life Span: | 100000hours | Cabinet Size: | 640x480mm |
Refresh Rate: | 3840Hz/7680HZ | Warranty: | 5 Years |
Type: | LED | Panel Size: | 640*480MM |
HS Code: | 8531200000 |
Model | P1.2 | P1.5 | P1.6 | P1.8 | P2 | P2.5 | P3 | P4 | |||||||
Pixel Pitch(mm) | 1.25 | 1.53 | 1.66 | 1.86 | 2 | 2.5 | 3 | 4 | |||||||
Pixel Matrix Per Sq.m | 422500 | 422500 | 360000 | 288906 | 250000 | 160000 | 90000 | 62500 | |||||||
Pixel Configuration | SMD1212 | SMD1212 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD2121 | SMD2121 | |||||||
Cabinet Resolution | 415x312 | 415x312 | 384x288 | 344x258 | 320x240 | 256x192 | 192x144 | 160x120 | |||||||
Power Con.(W/㎡) (Max / Avg) | 600W/200W | 600W/200W | 600W/200W | 580W/180W | 580W/180W | 550W/160W | 450W/160W | 450W/160W | |||||||
Refresh Rate (HZ) | 7680 | 7680 | 7680 | 7680 | 7680 | 7680 | 7680 | 7680 | |||||||
Brightness (cd/㎡) | 500-900 | ||||||||||||||
Module Dimension | 320x160mm / 1.05x0.53ft | ||||||||||||||
Cabinet Dimension | 640x480mm / 2.10x1.57ft | ||||||||||||||
Cabinet Material | Die Casting Aluminum | ||||||||||||||
Cabinet Weight | 6.5KG | ||||||||||||||
Service Access | Front | ||||||||||||||
Grey Scale (bit) | 14-22 | ||||||||||||||
Viewing Angle (H/V) | 160°/160° | ||||||||||||||
IP Rate | IP55 | ||||||||||||||
Operation Temperature | -20℃ ~ +80°℃ | ||||||||||||||
Input Voltage (AC) | 110V / 220V |
