Product Details:
|
Color Temperature: | 6500K | Warranty: | 5 Years |
---|---|---|---|
Resolution: | 7680×4320 (8K) | Waterproof: | IP33 |
Contrast Ratio: | 3000:1 | Power Consumption: | 150W/㎡ |
Color Depth: | 14-22bit | Refresh Rate: | 120HZ, 7680Hz |
Mounting Options: | Wall Mount | Power Supply: | 100-240V AC |
Content Management System: | Not Available | Sunlight Readable: | No |
Color Gamut: | DCI-P3 95% | HDR Support: | HDR10+ |
Remote Device Management: | Not Available | Usage Environment: | Hotel, Shop Window, Shop, Commercial, Exhibition, Indoor Store, Showroom, TV Studio, Indoor Fixed Installation, Shopping Malls |
Type: | LED | Application: | Indoor |
Use: | Advertising Publish, Shopping Mall, Indoor Led Display, Indoor LED Video Wall | Media Available: | Datasheet, Photo |
Color: | FULL COLOR | Pixel Density: | 640000dots/m2 |
Pixels: | 1.25 | Brightness: | Other |
Usage: | Indoor | Cabinet Size: | 960x480mm 640x480mm 640x640mm 320x640x68mm |
Module Size: | 320x160mm | Weight: | 4.6KG/PCS |
Panel Material: | Die-casting Aluminum | Pixel Resolution: | 640000dots/m2 |
Life Span: | 100000hours | Installation: | Grane Gider Hoisting And Fixed Installation |
Model | P1.2 | P1.5 | P1.6 | P1.8 | P2 | P2.5 | P3 | P4 | |||||||
Pixel Pitch(mm) | 1.25 | 1.53 | 1.66 | 1.86 | 2 | 2.5 | 3 | 4 | |||||||
Pixel Matrix Per Sq.m | 422500 | 422500 | 360000 | 288906 | 250000 | 160000 | 90000 | 62500 | |||||||
Pixel Configuration | SMD1212 | SMD1212 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD2121 | SMD2121 | |||||||
Cabinet Resolution | 415x312 | 415x312 | 384x288 | 344x258 | 320x240 | 256x192 | 192x144 | 160x120 | |||||||
Power Con.(W/㎡) (Max / Avg) | 600W/200W | 600W/200W | 600W/200W | 580W/180W | 580W/180W | 550W/160W | 450W/160W | 450W/160W | |||||||
Refresh Rate (HZ) | ≥3840(7680 Optional) | ≥3840 (7680 Optional) | 3840 (7680 Optional) | 3840 (7680 Optional) | 3840 (7680 Optional) | ≥1920 (7680 Optional) | ≥1920 (7680 Optional) | ≥1920 (7680 Optional) | |||||||
Brightness (cd/㎡) | 500-900 | ||||||||||||||
Module Dimension | 320x160mm / 1.05x0.53ft | ||||||||||||||
Cabinet Dimension | 640x480mm / 2.10x1.57ft | ||||||||||||||
Cabinet Material | Die Casting Aluminum | ||||||||||||||
Cabinet Weight | 4.6KG | ||||||||||||||
Service Access | Front | ||||||||||||||
Grey Scale (bit) | 14-22bit | ||||||||||||||
Viewing Angle (H/V) | 160°/160° | ||||||||||||||
IP Rate | IP45 | ||||||||||||||
Operation Temperature | -20℃ ~ +80°℃ | ||||||||||||||
Input Voltage (AC) | 110V / 220V |
