Product Details:
|
Application: | Indoor, Outdoor | Warranty: | 1 Year |
---|---|---|---|
Color: | Full Color | Supplier Type: | Original Manufacturer, ODM, OEM |
Media Available: | Datasheet, Photo | Use: | Rental Led Screen, Outdoor LED Screen, Indoor LED Screen, STAGE |
Function: | SDK | Pixels: | 3.91mm |
Specification: | Video Wall | Screen Type: | No |
Brightness: | >1200cd/sqm | Aspect Ratio: | 16:9 |
Pixel Density: | 65536dot/m2 | Contrast Ratio: | 30000:1 |
Color Depth: | 16-22bit | Lifespan (hours): | 100000hr |
Ip Rating: | IP45 | Resolution: | 2K/4K/8K |
View Angle(h/v): | 160/160° | Usage: | Indoor/outdoor |
Display Function: | Video | Cabinet Material: | Die-casting |
LED Type: | SMD1921 | Module Size: | 250*250mm |
Pixel Density: | 65536 DOT/M2 | Brightness: | 5500cd/sqm |
Life Span: | 100000hours | Refresh Rate: | 3840Hz/7680Hz |
Warranty: | 5 Years |
Pixel pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm | |||
Pixels per cabinet | 192×192 (HxV) | 168×168 (HxV) | 128×128 (HxV) | 104×104 (HxV) | |||
LED lifetime | 100,000h (video – 50% brightness) | ||||||
Brightness | ≥1000 nits; | ||||||
Module size | 250*250mm | ||||||
Module resolution | 96*96dots | 84*84dots | 64*64dots | 52*52dots | |||
Refresh rate | 960-1,920Hz | ||||||
Hor. viewing angle | 140° +/-5° (@50% brightness) | ||||||
Vert. viewing angle | 140° +/-5° (@50% brightness) | ||||||
Brightness uniformity | >98% | ||||||
Dimming | 0-100% | ||||||
Grey Level | 14 bits | ||||||
Avg Power consumption | 350 W/m² | 320 W/m² | 300 W/m² | 280 W/m² | |||
Max Power consumption | 680 W/m² | 640 W/m² | 620 W/m² | 600 W/m² | |||
Operation power voltage | 100-240V / 50-60Hz | ||||||
Operational temperature | -10°C to +40°C / 14°F to 104°F | ||||||
Operational humidity | 10-80% | ||||||
IP rating | IP54 for Indoor, IP65 for Outdoor | ||||||
Dimensions | 500 x 500 x 71 mm / 500 x 1000 x 71 mm (WxHxD) | ||||||
Weight / Tile | 7 kg / 13 kg | ||||||
Serviceability | Front and back service | ||||||
Certifications | CE, UL, FCC class A, RoHS, WEE, REACH | ||||||
Warranty | 5 years standard product warranty |
