Product Details:
|
Color Depth: | 14-22bit | Type: | LED |
---|---|---|---|
Application: | Indoor | Use: | Led Screen Indoor, Indoor Led Display, Digital Signage And Displays |
Media Available: | Datasheet, Photo | Color: | Full Color |
Pixel Density: | 288906dots | Pixels: | 1.2MM |
Usage: | Indoor | Display Function: | Video |
Material: | Die-casting | Module Size: | 320mmx160mm |
Viewing Angle: | H:160° V:160° | Brightness: | 800cd/sqm, 1000nit |
Pixel Density: | 288906pix/m² | Life Span: | 100000hours |
Refresh Rate: | 3840Hz/7680Hz | Warranty: | 5 Years |
Supplier Type: | Original Manufacturer, ODM, OEM | Function: | SDK |
Specification: | Video Wall | Screen Type: | No |
IP Rating: | IP51 | Lifespan (hours): | 100000 |
Panel Size: | 640*480MM/Customization | Contrast Ratio: | 30000:1 |
View Angle(H/V): | 160:160° | HS Code: | 8531200000 |
Resolution: | 2K/4K/8K |
Model | P1.2 | P1.5 | P1.6 | P1.8 | P2 | P2.5 | P3 | P4 | |||||||
Pixel Pitch(mm) | 1.25 | 1.53 | 1.66 | 1.86 | 2 | 2.5 | 3 | 4 | |||||||
Pixel Matrix Per Sq.m | 422500 | 422500 | 360000 | 288906 | 250000 | 160000 | 90000 | 62500 | |||||||
Pixel Configuration | SMD1212 | SMD1212 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD2121 | SMD2121 | |||||||
Cabinet Resolution | 415x312 | 415x312 | 384x288 | 344x258 | 320x240 | 256x192 | 192x144 | 160x120 | |||||||
Power Con.(W/㎡) (Max / Avg) | 600W/200W | 600W/200W | 600W/200W | 580W/180W | 580W/180W | 550W/160W | 450W/160W | 450W/160W | |||||||
Refresh Rate (HZ) | ≥3840 | ≥3840 | 3840 | 3840 | 3840 | ≥1920 | ≥1920 | ≥1920 | |||||||
Brightness (cd/㎡) | 500-900 | ||||||||||||||
Module Dimension | 320x160mm / 1.05x0.53ft | ||||||||||||||
Cabinet Dimension | 640x480mm / 2.10x1.57ft | ||||||||||||||
Cabinet Material | Die Casting Aluminum | ||||||||||||||
Cabinet Weight | 4.6KG | ||||||||||||||
Service Access | Front | ||||||||||||||
Grey Scale (bit) | 14-22bit | ||||||||||||||
Viewing Angle (H/V) | 160°/160° | ||||||||||||||
IP Rate | IP45 | ||||||||||||||
Operation Temperature | -20℃ ~ +80°℃ | ||||||||||||||
Input Voltage (AC) | 110V / 220V |
