Application: | Indoor, Outdoor | Color: | Full Color |
---|---|---|---|
Supplier Type: | Original Manufacturer, ODM, Other, OEM | Media Available: | Datasheet, Photo, EDA/CAD Models |
Use: | Rental Led Display Screen, Renta Led Screen, Indoor Rental Led Screen, Outdoor Rental Led Screen, Indoor, Outdoor, Rental | Function: | SDK |
Pixels: | 2.604mm | Specification: | Video Wall |
Screen Type: | No | Brightness: | >800cd/sqm |
Pixel Density: | 147456dots | Contrast Ratio: | 30000:1 |
Color Depth: | 16 - 24bit | Lifespan (hours): | 100000hours |
Ip Rating: | Indoor IP45 / Outdoor IP67 | Resolution: | 2K/4K/8K |
View Angle(h/v): | 160/140° | Usage: | Indoor/outdoor Rental |
Display Function: | Video | Cabinet Material: | Die-casting |
LED Type: | SMD1920(black) | Module Size: | 250*250mm |
Pixel Density: | 147,456 DOT/M2 | Brightness: | 1000cd/sqm |
Life Span: | 100000hours | Refresh Rate: | 7680Hz/3840Hz |
Warranty: | 5 Years | Type: | LED |
Panel Size: | 500*500MM | HS Code: | 8531200000 |
Indoor Rental Series | ||||||||
Type | P2.604 | P2.97 | P3.91 | P4.81 | ||||
Pixel Pitch(mm) | 2.604 | 2.97 | 3.91 | 4.81 | ||||
Physical Density (dot/sqm) | 147,456 | 112,896 | 65,536 | 43,264 | ||||
Brightness | ≥900nits | ≥900nits | ≥900nits | ≥900nits | ||||
Scanning Mode | 1/32 | 1/28 | 1/16 | 1/13 | ||||
LED type | SMD1515 | SMD1515 | SMD2121 | SMD2121 | ||||
Module Size | 250×250mm | 250×250mm | 250×250mm | 250×250mm | ||||
Module Resolution | 96×96pixels | 84×84pixels | 64×64pixels | 52×52pixels | ||||
Grey Scale | 16bit-22bit | 16bit-22bit | 16bit-22bit | 16bit-22bit | ||||
Refresh Rate | ≥3840Hz-7680HZ for XR Panels | ≥3840Hz-7680HZ for XR Panels | ≥3840Hz-7680HZ for XR Panels | ≥3840Hz-7680HZ for XR Panels | ||||
Average Power | 150w/m² | 150w/m² | 150w/m² | 150w/m² | ||||
Cabinet Size | 500×500mm | 500×500mm | 500×500mm | 500×500mm | ||||
Cabinet Weight | 7.5kg | 7.5kg | 7.5kg | 7.5kg | ||||
Cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | ||||
Input Voltage | AC 110V~220V ±10% | AC 110V~220V ±10% | AC 110V~220V ±10% | AC 110V~220V ±10% | ||||
Protection Level | IP45 | IP45 | IP45 | IP45 |
Outdoor Rental Series | ||||||
Product | P2.976 | P3.91 | P4.81 | |||
Pitch(mm) | 2.976 | 3.91 | 4.81 | |||
Density(pixels/m2) | 112896 | 65536 | 43264 | |||
LED Type | SMD1921 | SMD2121 | SMD1921 | |||
Brightness | 4500nits | 5000nits | 6000nits | |||
Scan Method | 1/21 | 1/16 | 1/13 | |||
Cabinet Size(mm) | 500mm*500mm / 500mm*1000mm | |||||
Module Size | 250*250mm | |||||
Cabinet Material | Die casting Aluminum | |||||
Cabinet Weight | 7.5kg / 13kg | |||||
Protection Level | IP67 | |||||
Cabinet Maintenance | Module Front Service & Rear Service | |||||
Max Power Consumption | 210w/panel | 210w/panel | 210w/panel | |||
Average Power Consumption | 105w/panel | 105w/panel | 105w/panel | |||
Refresh Rate | 3840HZ / 1920Hz | |||||
Grey Scale | 16 bit-24bit | |||||
Viewing Angle | H140, V140° | |||||
Voltage | AC110~220V(50-60Hz) | |||||
Working Temperature | -22 oC - 149 oC | |||||
Working Humidity | 10% -- 90%RH | |||||
Color Temperature | 2000-10000K | |||||
Certificationa | EMC/CE/ROHS/CCC/FCC |
