Product Details:
|
Application: | Indoor, Outdoor | Warranty: | 5 Years |
---|---|---|---|
Color: | Full Color | Supplier Type: | Original Manufacturer, ODM, Other |
Media Available: | Datasheet, Photo | Use: | Rental Led Screens |
Function: | SDK | Pixels: | 3.91mm |
Specification: | Video Wall | Screen Type: | No |
Brightness: | >1000cd/sqm | Aspect Ratio: | 16:9, 1:1 |
Pixel Density: | 65536 Dots/m² | Contrast Ratio: | 30000:1 |
Color Depth: | 14-22bit | Lifespan (hours): | 100000hr |
Ip Rating: | Ip65 | Installation Type: | Hanging Installation Stacking Installation |
Resolution: | 7680Hz | View Angle(h/v): | 160/140° |
Panel Brand: | ReissDisplay | Operation System: | Other |
Display Function: | ANIMATION, Video | Usage: | Indoor/outdoor |
Cabinet Material: | Die-casting | LED Type: | SMD2121(black) |
Module Size: | 250*250mm | Pixel Density: | 65536 DOT/M2 |
Brightness: | 1000~5500cd/sqm | Life Span: | 100000hours |
Refresh Rate: | 7680Hz |
Cabinet Model No. | 500x500RT |
Cabinet Size | Straight 500mm*500mm*67mm Curve 500mm*500mm*67mm |
Cabinet Weight | 4.2 kg (Aluminum Door/Suite and power supply not included) |
Cabinet Material | Aluminum |
Suite Quan. | 8pcs of Modules 250mm*500mm per cabinet |
Installation | Crane girder hoisting and fixed installation |
Color | Cabinet color: Black Door color: Black / Blue /Orange |
Application Scope of Pixel Pitch | P2 P2.5 P2.604 P2.976 P3.91 P4.81 P5.95 |
Working Environment | Both indoor and outdoor |
Standard Accessories | 1 door 1 handle2 positioning lins 1.3 Connecting pieces 4 Quick locks (2 quick locks+2radian lock) |
Pixel pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm | |||
Pixels per cabinet | 192×384 (HxV) | 168×336 (HxV) | 128×256 (HxV) | 104×208 (HxV) | |||
LED lifetime | 100,000h (video – 50% brightness) | ||||||
Brightness | ≥1000 nits ~ 5500 nits | ||||||
Module size | 250*250mm | ||||||
Module resolution | 96*96dots | 84*84dots | 64*64dots | 52*52dots | |||
Refresh rate | 3840Hz/7680Hz | ||||||
Hor. viewing angle | 140° +/-5° (@50% brightness) | ||||||
Vert. viewing angle | 140° +/-5° (@50% brightness) | ||||||
Brightness uniformity | >98% | ||||||
Dimming | 0-100% | ||||||
Grey Level | 14 bits | ||||||
Avg Power consumption | 350 W/m² | 320 W/m² | 300 W/m² | 280 W/m² | |||
Max Power consumption | 680 W/m² | 640 W/m² | 620 W/m² | 600 W/m² | |||
Operation power voltage | 100-240V / 50-60Hz | ||||||
Operational temperature | -10°C to +40°C / 14°F to 104°F | ||||||
Operational humidity | 10-80% | ||||||
IP rating | IP54 for Indoor, IP65 for Outdoor | ||||||
Dimensions | 500 x 1000 x 67 mm (WxHxD)/ 500 x 500 x67 mm (WxHxD) | ||||||
Weight / Tile | 13kg / 7kg | ||||||
Serviceability | Front and back service | ||||||
Certifications | CE, UL, FCC class A, RoHS, WEE, REACH | ||||||
Warranty | 5 years standard product warranty |
